EVA High Magnification Foaming Machine

Basic Info

Model No.: JHF2

Brand: QuanJinHe

Place Of Origin: China

Status: New

Processing Type: Foaming Machine

Product Category: Foam Net, Plastic Sheet, Pvc Profile

Certification: Ce, Ul

Warranty Period: 1 Year

Core Selling Point: Automatic, Multifunctional, Competitive Price, High-Accuracy, High Safety Level, Energy Saving, Sustainable, Long Service Life, High Productivity, Easy To Operate, Flexible Manufacturing

Out-of-warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service

Applicable Industry: Building Material Shops, Manufacturing Plant, Retail, Construction Works

Marketing Type: Ordinary Product

Mechanical Test Report: Provided

Video Factory Inspection: Provided

Core Component Warranty Period: 1 Year

Core Components: Bearing, Motor, Pump, Gear, Plc, Engine, Gearbox

Power: 5.5 kw

Plate Size: 1000x2000, Customized

Mold Size: 1150x2150 mm

Layers Distance: 150 mm

Layers: 6-10 layers

Equipment Composition: main machine*1,hydraulic station*1 and electric control box*1

Heating: Steam

Cooling: Water

Application: EVA rubber plastic product, sheets, shoes, tiles, mats

Product Name: EVA High Magnification Foaming Machine

Additional Info

Packaging: Packing frame and plastic film, then load into containers

Productivity: 100 sets per year

Transportation: Ocean,Land

Place of Origin: China

Supply Ability: 100 sets per year

Certificate: ISO 9001; ISO 14001

HS Code: 84778000

Port: Shanghai

Product Description

EVA High Magnification Foaming Machine

Eva Secondary Foaming Machine is used for high rate foaming of EVA, PE, EPDM, SBR rubber and plastic materials.(Expansion rate:25-45 times). It's a kind of Rubber And Plastic Foaming Machine. Normally this machine works after EVA Foaming Machine.

1. Analysis of the diverse applications and characteristics of EVA materials

EVA， The full name is ethylene vinyl acetate copolymer, which has a wide range of applications in multiple industries. Its unique molecular structure allows EVA to maintain the excellent properties of polyethylene while also possessing outstanding flexibility, impact resistance, and compatibility with fillers. In addition, EVA also exhibits excellent heat sealing performance, further expanding its application range.

2. Foam shoe material

Shoe material is an important application area of EVA resin. In shoe materials, the vinyl acetate content of EVA resin is usually controlled between 15% and 22%. Shoe materials made using EVA resin foaming technology are not only soft and elastic, but also have chemical corrosion resistance. This makes EVA an ideal choice for shoe materials such as mid to high end travel shoes, hiking shoes, slippers, and sandals. In addition, this material is widely used in various fields such as soundproofing boards, gymnastics mats, and sealing materials.

3. Thin film

EVA resin is also widely used in the field of thin films. Among them, functional greenhouse film is an important application direction of EVA film. Due to the non polarity of polyethylene, its anti fog droplet performance is difficult to sustain. However, adding a certain amount of EVA resin can not only significantly improve the light transmittance of the film, but also effectively prolong the duration of anti fog droplet performance. In addition, EVA can also be used to produce various types of film products such as packaging films, medical films, laminated films, and casting films.

Technical Data
