EVA Supercritical Foaming Machine for mat

Basic Info

Model No.: JHFC

Brand: QuanJinHe

Place Of Origin: China

Status: New

Processing Type: Foaming Machine

Product Category: Laminated Tube, Bubble Film, Fast Food Box, Foam Net, Pe Film, Pet Strap, Plastic Bag, Plastic Bottle, Plastic Cup, Plastic Pipe, Plastic Rope, Plastic Sheet, Pp Woven Bag, Pvc Profile

Certification: Ce, Ul

Warranty Period: 1 Year

Core Selling Point: Automatic, Multifunctional, Competitive Price, High-Accuracy, High Safety Level, Energy Saving, Sustainable, Long Service Life, High Productivity, Easy To Operate, Flexible Manufacturing

Out-of-warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service

Applicable Industry: Building Material Shops, Manufacturing Plant, Retail, Construction Works

Marketing Type: Ordinary Product

Mechanical Test Report: Provided

Video Factory Inspection: Provided

Core Component Warranty Period: 1 Year

Core Components: Bearing, Motor, Pump, Gear, Plc, Other, Pressure Vessel, Engine, Gearbox

Voltage: Customized

Pressure: 1800 ton

Layers: 6-12 layers

Layer Distance: 180 mm

Control Mode: PLC+GOT

Application: Aerospace, rail transit, automobiles, surface vessels, wind turbineblades, buffer packaging, cold chain logistics, sports protection,biomedicine, etc.

Foaming Agent: CO2; N2

Frequency: Customized

Working Table: 1200x1700 mm, Customized

Product Name: EVA Supercritical Foaming Press Machine for shoe

Additional Info

Packaging: Packing frame and plastic film, then load into containers

Productivity: 200 sets per year

Transportation: Ocean,Land

Place of Origin: China

Supply Ability: 200 sets per year

Certificate: ISO 9001; ISO 14001

HS Code: 84778000

Port: Shanghai

Product Description

EVA Supercritical Foaming Press Machine for shoe

Usage: This kind of Rubber And Plastic Foaming Machine is a specialized foaming machine made according to the supercritical process of polymer materials. We also have noraml EVA Foaming Machine and Secondary EVA Foaming Machine for your choice.

There are currently four main types of raw materials for supercritical foaming: EVA、TPU、TPEE、PEBA。

EVA (ethylene vinyl acetate) is the earliest, most mature, and widely used foam shoe material. Its various properties are relatively ordinary, but its durability index is relatively backward. After long-term wear, it is easy to be "flattened", thereby reducing rebound and cushioning performance.

TPU (thermoplastic polyurethane) has excellent rebound performance and strong durability, but it is relatively heavy and will generate heat after long-term pressure deformation. TPU is divided into aromatic and aliphatic types. Overall, aliphatic compounds have better performance than aromatic compounds.

TPEE (thermoplastic polyester) can be regarded as an upgraded version of TPU, with little difference in rebound, durability and other indicators compared to TPU, but significant improvement in lightweight indicators.

PEBA (polyether block amide), also known as nylon elastomer, has the highest level of resilience, lightweight performance, and durability performance compared to TPU and TPEE, making it a standard midsole for top sports shoes. PEBA has a high cost, and it is common to use PEBA mixed with EVA, TPU and other materials for foaming to reduce costs.

Technical Data:
